The RX-5000 TBR/W is Leupold's flagship long-range rangefinder, built for hunters and long-range shooters who need ballistically calculated ranges, not just raw distance. It pairs a Hornady 4DOF® ballistic calculator with true ballistic range/wind (TBR/W) compensation, giving you an angle- and wind-adjusted "hold" distance instead of a straight-line number that doesn't account for real-world shooting conditions.
Connected hunting: Pair the RX-5000 with the Leupold Link app over Bluetooth to drop pinned GPS waypoints directly onto your onX Hunt maps, and receive free firmware updates as Leupold adds new ballistic profiles.
Features
- Hornady 4DOF® ballistic calculator with real bullet flight-path tracking
- TBR/W (True Ballistic Range/Wind) angle- and wind-compensated holds
- Precision Cut Archery software for bow hunters
- Bow Mode with TRIG function (accurate to ~70 yards on angles under 20°)
- Bluetooth connectivity via the Leupold Link app for onX Hunt GPS waypoint pinning
- Digital compass with onX Hunt integration
- Long Range (LONG) mode for extended-distance ranging
- Line of Sight (LOS) mode for straight-line distance
- Last Target technology cuts through rain, fog, and snow for a reliable read
- Selectable reticles
- Arca-Swiss compatible tripod saddle mount
- 100% waterproof and fog proof
Specifications
- Magnification: 8x
- Objective aperture: 30mm
- Max range – reflective targets: 5000+ yd
- Max range – trees: 3100 yd
- Max range – deer: 2000 yd
- Minimum range: 6 yards
- Accuracy: ±0.5 yd to 125 yd, ±2 yd to 1000 yd, ±0.2% beyond 1000 yd
- Angular field of view: 5.5° (289 ft @ 1000 yd)
- Eye relief: 17.3mm | Diopter range: -3 to +3
- Weight: 9.7 oz
- Dimensions (L x H x W): 4.4 x 3.1 x 1.6 in
- Display: Red OLED, selectable reticles
- Battery: CR123, 3000+ actuations
- Laser classification: Class 1M
- Warranty: Lifetime Guarantee
Part #184681 – Black/Black, Red OLED Selectable
