4MM AXIS™ LONG RANGE & LONG RANGE MATCH GRADE!

Industry-leading carbon AXIS now available in a 4MM micro-diameter. The AXIS 4MM is engineered with a specific 100% carbon-fiber layup for increased velocity. Includes Easton’s new Aluminum point outsert to boost both strength and front-of-center accuracy.

DETAILS:

4mm micro-diameter uniform ACU-Carbon fiber construction
Pre-installed 4mm Microlite nocks
Straightness: .003"
Weight: 400 spine 7.4 gpi | 340 spine 8.3 gpi |300 spine 9.3 gpi | 250 spine 9.8 gpi
Includes 8/32 Easton 4MM Half-Outs (Aluminum) #2070887 for optimum FOC
Weight: 50 grain
Precise two-point interface with shaft increases strength
1/16" +/- shaft engagement under half out
Spine specific construction allows for the tightest tolerance between components
Non-reflective black anodized finish
Adds 1" to carbon length
400 spine use #1 | 340 spine use #2 | 300 spine use #4 | 250 spine use #4
Compatible with Easton 4MM Titanium Half-Out #2070807
Weight: 55 grains
Uses 5/16" diameter field point

SIZE	SHAFT WEIGHT GPI	SPINE @ 28″ SPAN DEFLECTION IN INCHES	STOCK LENGTH	DEEP 6 FIELD POINT 100/125 GRAINS	O.D. INCHES	4MM HALFOUT
400	7.4	0.400	31.5″	DP6-4	0.229	#1
340	8.3	0.340	32″	DP6-4	0.234	#2
300	9.3	0.300	32.5″	DP6-6	0.241	#3
250	9.8	0.250	33″	DP6-6	0.244	#4

4mm Axis

4mm Axis Match Grade

Includes NEW aluminum point outserts (50 grains)
Micro-Diameter, 100% carbon hunting arrow- increased velocity
Reduced friction in flight and at impact to offer optimized FOC, enhance target penetration, and better accuracy at long range
4 popular hunting spine sizes- 250, 300, 340, and 400
4MM nocks pre-installed
Made in USA
Straightness: +/- .003″ [Match Grade: +/- .001″]
